IS200VTURH1BAC

0 نفر
موجودی انبار :
حداکثر توان تولید در سفارش :
زمان تولید :
قیمت :
سفارش دهید
محصولات مشابه
IS200TRPGH1BDE
IS200TRPGH1BDE
IS200TSVOH1BDC
IS200TSVOH1BDC
IS200TTPWH1AAB
IS200TTPWH1AAB
IS200TBAIH1BBB
IS200TBAIH1BBB
DS200DACAG1ACD
DS200DACAG1ACD
IS200TBTCH1BBB
IS200TBTCH1BBB
IS200VTCC
IS200VTCC
IS200TPROH1BCB
IS200TPROH1BCB
IS200VVIB
IS200VVIB
IS200TTURH1BED
IS200TTURH1BED
IS215VPROH1BGG
IS215VPROH1BGG
IS200TVIBH2BCC
IS200TVIBH2BCC
DS200TCPDG2BEC
DS200TCPDG2BEC
IS200VAICH1CBA
IS200VAICH1CBA
IS200VSVO
IS200VSVO
IS200TRTDH1CCC
IS200TRTDH1CCC
IS215VCMIH2CC
IS215VCMIH2CC

نقد و بررسی تخصصی IS200VTURH1BAC

In the simplex application, up to four pulse rate signals may be used to measure turbine speed. Generator and bus voltages are brought into VTUR for automatic synchronizing in conjunction with the turbine controller and excitation system. TTUR has permissive generator synchronizing relays and controls the main breaker relay coli 52G. Shaft voltage is picked up with brushes and monitored along with the current to the machine case.

مشخصات فنی IS200VTURH1BAC

    مشخصات کارت
  • Trip solenoids (TRPG) Solenoids drow up to 1A at 125 V dc and have a time constant of L/R=0.1 sec
  • Power supply voltage TTUR:Nominal 125 V dc to breaker coil
  • MPU pulse rate range 2Hz to 20 kHz
  • MPU pulse rate accuracy 0.05%of reading
  • MPU input circuit 27mV pk (detects 2 rpm speed)
  • Shaft voltage monitor Signal is frequency of ± 5 V dc (0-1MHz) pulses from 0 to 2,000 Hz
  • Shaft voltage wiring Up to 300 m (984 ft), with maximum two-way cable resistance of 15 ohms
  • Shaft current input Measures shaft current in amps ac (shunt voltage up to 0.1 V pp)
  • Generator and bus voltage Twp single phase potential transformers
  • Synchromizing measurements Frequency accuracy 0.05% over 45 to 66 Hz range. Zero crossing of the inputs is monitored on the rising slope. Phase difference measurement is better than ± 1 degree.
    مشخصات
  • Shaft voltage ac test Applies a test voltage of 1 kHz to the input of the VTUR voltage circuit (Rmodule only)
.
